Elektromagnetický ventil, EV310A, Funkce: NC, Příruba, 0.03 m³/h, FKM
Kód: 032H878502Detailní popis produktu
Popis produktu není dostupný
Doplňkové parametry
| Kategorie: | EV310A |
|---|---|
| Hmotnost: | 0.27 kg |
| EAN: | 5702423203659 |
| Housing material (EF001596): | Brass |
| Medium temperature range [°C] [max]: | 100 |
| Min. pressure difference (EF020189): | 0.000 |
| Kvs value (EF022466): | 0.030 |
| Specification key: | EV310A 1B FL32 F NC040 AM024D |
| Height (EF000040): | 96 |
| SCIP dossier no.: | 049058ad-6d73-4ec9-9d2b-b574054e817d |
| Actuator system [mm]: | 9.0 |
| Material quality (EF001257): | Other |
| Function: | NC |
| Electrical connection (EF003701): | Other |
| Max. test pressure [psig]: | 609.0 |
| Medium temperature range [°C] [min]: | -10 |
| Electrical connection: | Spade DIN 43650-A |
| Ambient temperature max. [°C]: | 50 |
| Serviceable: | Solenoid valve spare parts |
| Seal Material: | FKM |
| Ambient temperature max. [°F]: | 122 |
| Surface protection (EF000139): | Other |
| Enclosure rating IP: | IP65 |
| Explosion safety (EF003996): | None |
| Power consumption [W] DC: | 9.0 |
| Operation: | Direct-operated |
| Product accessories: | Flanges, Solenoid coil accessories, Solenoid valve accessories |
| Connection type: | Flange |
| Connection material: | Brass |
| EEE category: | 5 small equipment (any external dimension <lt/> 50 cm) |
| Body material: | Brass |
| Differential pressure [psi] [min]: | 0.000 |
| Emergency manual operation (EF025189): | Other |
| Orifice size [mm]: | 1.00 |
| Medium temperature range [°F] [min]: | 14 |
| Fluid Group: | 1 |
| Actuator size: | 9 mm |
| Cv value [gal/min]: | 0.030 |
| Actuator size [in]: | 0.35 in |
| China RoHS compliance: | Out of scope |
| Packing format: | Multi pack |
| In scope of WEEE: | Yes |
| Kv value [m³/h]: | 0.030 |
| Approval: | CE |
| Differential pressure [bar] [min]: | 0.000 |
| Actuator: | A |
| Type designation: | EV310A 1 |
| REACH Candidate List substances: | Lead (CAS no. 7439-92-1) |
| Differential pressure [bar] [max]: | 28.000 |
| Number of ways: | 3/2 |
| Contains batteries: | No |
| CE mark: | Yes |
| Voltage type (EF000187): | DC |
| EU RoHS exemption clause: | 6(c) |
| EU RoHS compliance: | Yes with exemptions |
| Max. Working Pressure [bar]: | 28.0 |
| Medium temperature range [°F] [max]: | 212 |
| Orifice size fraction [in]: | 3/64 in |
| Differential pressure [psi] [max]: | 406.000 |
| Coil type: | AM |
| Application: | Open |
| Degree of protection (IP) (EF005474): | IP65 |
| Connection size [mm]: | 32 |
| Connection voltage (EF003625): | 24 |
| SCIP dossier product name: | EV310A - solenoid valve |
| Max. test pressure [bar]: | 42.0 |
| Supply voltage [V] DC: | 24.00 |
| Model (EF000010): | Straight |
| Quantity per packing format: | 15 |
| Freeflow (EF020116): | FALSE |
| Max. Working Pressure [psig]: | 406 |
| Media recommendations: | Oil,Comp.Air,Vacuum |
-
