Elektromagnetický ventil, EV251B, Funkce: NC, G, 3/8, 1.5 m³/h, NBR
Kód: 032U538016Související produkty
![Cívka solenoidu, BB024AS, Štítek DIN, Napájecí napětí [V] AC: 24, Multi balení](https://cdn.myshoptet.com/usr/www.damatech.eu/user/shop/detail/4536_civka-solenoidu--bb024as--stitek-din--napajeci-napeti--v--ac--24--multi-baleni.png?67e88fe6
)
Detailní popis produktu
Popis produktu není dostupný
Doplňkové parametry
| Kategorie: | EV251B univerzální |
|---|---|
| Hmotnost: | 0.58 kg |
| EAN: | 5702423292509 |
| Housing material (EF001596): | Brass |
| Medium temperature range [°C] [max]: | 70 |
| Min. pressure difference (EF020189): | 0.000 |
| Connection standard: | ISO 228-1 |
| Est. time to close, water [ms]: | 300 |
| China RoHS exemption clause: | 7.3 |
| Supply voltage [V] AC: | 24 |
| Est. time to open, water [ms]: | 50 |
| Specification key: | EV251B 10B G 38N NC688 BB024AS |
| Height (EF000040): | 93 |
| SCIP dossier no.: | 1b9c4d1e-3db1-4cbf-b890-a2f5466a0ea9 |
| Actuator system [mm]: | 13.5 |
| Material quality (EF001257): | Other |
| Supply voltage 50Hz Max [V]: | 24 |
| Function: | NC |
| Electrical connection (EF003701): | Other |
| Max. test pressure [psig]: | 217.5 |
| Medium temperature range [°C] [min]: | -10 |
| Electrical connection: | Spade DIN 43650-A |
| Ambient temperature max. [°C]: | 80 |
| Connection Internal/External: | Internal |
| Serviceable: | Solenoid valve spare parts |
| Seal Material: | NBR |
| Ambient temperature max. [°F]: | 176 |
| Surface protection (EF000139): | Other |
| Enclosure rating IP: | IP65 |
| Explosion safety (EF003996): | None |
| Media tolerance comments: | Neutral media |
| Coil option: | Clip-on |
| Operation: | Assisted lift operated |
| Product accessories: | Solenoid coil accessories, Solenoid valve accessories |
| Connection type: | G |
| Connection size [in]: | 3/8 |
| Connection material: | Brass |
| EEE category: | 5 small equipment (any external dimension <lt/> 50 cm) |
| Body material: | Brass |
| Differential pressure [psi] [min]: | 0.000 |
| Emergency manual operation (EF025189): | Other |
| Orifice size [mm]: | 10.00 |
| Medium temperature range [°F] [min]: | 14 |
| Fluid Group: | 1 |
| Actuator size: | 13.5 mm |
| Cv value [gal/min]: | 1.750 |
| Actuator size [in]: | 0.53 in |
| China RoHS compliance: | Yes with exemptions |
| Packing format: | Multi pack |
| In scope of WEEE: | Yes |
| Kv value [m³/h]: | 1.500 |
| Approval: | CE |
| Differential pressure [bar] [min]: | 0.000 |
| Actuator: | B |
| Power consumption [W] 50Hz: | 11.0 |
| Type designation: | EV251B 10 |
| REACH Candidate List substances: | Lead (CAS no. 7439-92-1) |
| Differential pressure [bar] [max]: | 10.000 |
| Number of ways: | 2/2 |
| Contains batteries: | No |
| CE mark: | Yes |
| Frequency [Hz]: | 50 Hz |
| Voltage type (EF000187): | AC |
| EU RoHS exemption clause: | 6(c) |
| EU RoHS compliance: | Yes with exemptions |
| Max. Working Pressure [bar]: | 10.0 |
| Medium temperature range [°F] [max]: | 158 |
| Flow direction: | Single-flow |
| Orifice size fraction [in]: | 3/8 in |
| Flow direction indicator: | Embossed 1-way arrow |
| Differential pressure [psi] [max]: | 145.000 |
| Coil type: | BB |
| Application: | Closed and Drain |
| Degree of protection (IP) (EF005474): | IP65 |
| Connection voltage (EF003625): | 24 |
| Max media viscosity [cSt]: | 50 |
| SCIP dossier product name: | EV251B - solenoid valve |
| Max. test pressure [bar]: | 15.0 |
| Model (EF000010): | Straight |
| Quantity per packing format: | 24 |
| Freeflow (EF020116): | FALSE |
| Max. Working Pressure [psig]: | 145 |
| Media recommendations: | Water,Brine,Oil,Air |
-
