Připojovací sada pro připojení do propojovacího boxu
Kód: 109027Související produkty
Detailní popis produktu
Topné kabely, DEVIpipeguard™ Industry, 60W/m@10°C, 300 m, Napájecí napětí [V] AC: 230Doplňkové parametry
| Kategorie: | DEVIpipeguard™ Industry |
|---|---|
| Hmotnost: | 0.07 kg |
| EAN: | 5703466163498 |
| Cable width [mm]: | 11.80 |
| Cable screen: | Tinned copper braid |
| Outer sheath: | Fluorpolymer |
| Cable on drum: | Yes |
| Supply voltage [V] AC: | 230 |
| UL mark: | No |
| Flame retardant: | Yes |
| Height (EF000040): | 5.8 |
| Package width [mm]: | 340 |
| Package height [mm]: | 375 |
| Nominal voltage (EF000002): | 230 |
| Package depth [mm]: | 375 |
| Width (EF000008): | 11.80 |
| Colour (EF000007): | Black |
| Cold lead: | No |
| Application (EF000041): | Other |
| Certification company: | VDE |
| Installation temperature [°C] [Min]: | -40 |
| Cut to length: | No |
| Conductor insulation: | Self-limiting matrix |
| Cable output [W/m@°C]: | 60W/m@10°C |
| Application: | Pipe / tank frost protection |
| Product version: | Drum |
| Heating capacity (EF000344): | 10 |
| Cable height [mm]: | 5.8 |
| Bending diameter [mm] [Min]: | 50 |
| Filler material: | TPE |
| Warranty type: | 5-year product warranty |
| Cable type: | Twin conductor |
| UNSPSC CODE: | 26121601 |
| Element IP Class: | IPX7 |
| Cable length [m]: | 300.000 |
| China RoHS compliance: | Out of scope |
| Operating temperature [°C] [max]: | 120 |
| Approval: | CE, EAC |
| Length (EF001438): | 300 |
| REACH Candidate List substances: | No |
| Contains batteries: | No |
| Max. hold temperature (EF005979): | 120 |
| CE mark: | Yes |
| EU RoHS compliance: | Yes |
| Approval standard: | DIN VDE 0254: 1994-06 |
| Warranty [Year]: | 5 |
| Heating principle: | Self-limiting |
| Non operating temperature [°C] [Max]: | 190 |
| Lead free: | Yes |
| Diameter (EF000551): | 0 |
-
DEVIindustrie™ 30/60 (PT): Datový list
-
Connection kit for DEVIpipeguard™ 30/60 Industry: Instalační příručka
-
DEVI Pipes Application manual: Aplikační příručka
-
DEVI e-Warranty tool (User Guide): Uživatelská příručka
-
DEVI Product Warranty Process: Warranty
-
DEVI Self- limiting cables on drum: Instalační příručka
-
DEVI Product Warranty Process: Warranty
