Náhradní díl, 042N Coil Type B; 018F Coil Type B; 018Z cívka typu B, Kabelový konektor
Kód: 042N0265Související produkty
![Cívka solenoidu, BB024AS, Štítek DIN, Napájecí napětí [V] AC: 24, Multi balení](https://cdn.myshoptet.com/usr/www.damatech.eu/user/shop/detail/4536_civka-solenoidu--bb024as--stitek-din--napajeci-napeti--v--ac--24--multi-baleni.png?67e88fe6
)
![Cívka solenoidu, BB230AS, Štítek DIN, Napájecí napětí [V] AC: 230, Multi balení](https://cdn.myshoptet.com/usr/www.damatech.eu/user/shop/detail/4533_civka-solenoidu--bb230as--stitek-din--napajeci-napeti--v--ac--230--multi-baleni.png?67e88fe6
)
Detailní popis produktu
Popis produktu není dostupný
Doplňkové parametry
| Kategorie: | Příslušenství pro solenoidové ventily |
|---|---|
| Hmotnost: | 0.03 kg |
| EAN: | 5702423205899 |
| Conductor size, max. [mm2]: | 1.5 |
| Tolerance: | ± 10% |
| Type of accessory/spare part (EF000215): | Other |
| Ambient temperature range [°F] [min]: | -40 |
| China RoHS exemption clause: | No |
| Contact material: | CuZn (Cu/Sn plated) |
| Cable diameter [mm] [min]: | 6.0 |
| China RoHS compliance: | Yes |
| Supply voltage [V] AC: | 230 |
| Packing format: | Multi pack |
| Approval: | CE |
| Type designation: | Cable plug |
| REACH Candidate List substances: | No |
| Electrical connection standard: | EN 175301-803 |
| Contains batteries: | No |
| LED colour: | Red |
| Contacts: | 2 + PE |
| CE mark: | Yes |
| EU RoHS exemption clause: | No |
| Cable diameter [mm] [max]: | 8.0 |
| Cable diameter [in] [max]: | 0.32 |
| EU RoHS compliance: | Yes |
| Cable diameter [in] [min]: | 0.24 |
| Contact resistance max. [mOhm]: | 15 |
| Spare part (EF013237): | TRUE |
| Enclosure rating IP: | IP65 |
| Ambient temperature range [°C] [min]: | -40 |
| Ambient temperature range [°C] [max]: | 90 |
| Used for product: | 018F Coil Type B, 018Z Coil Type B, 042N Coil Type B |
| Gasket material: | NBR |
| Accessory (EF013236): | TRUE |
| Body type: | Translucent |
| Operating current max. [A]: | 16.00 |
| Electrical connection form: | Form A |
| Supply voltage [V] DC: | 230.00 |
| Gasket type: | Profiled |
| Quantity per packing format: | 100 |
| Ambient temperature range [°F] [max]: | 194 |
